Model No. | Hantek365A | Hantek365B | Hantek365C | Hantek365D | Hantek365E | Hantek365F |
True RMS | N | Y | N | Y | N | Y |
Lithium-Battery-Powered | N | N | Y | Y | Y | Y |
Bluetooth Connection | N | N | Y | Y | Y | Y |
iPad Supporting | N | N | N | N | Y |
Y |
Function | Range | Accuracy | Resolution |
DC Voltage | 60.00mV | ±1% ±1 digit | 10uV |
600.00mV | 100uV | ||
6.00V | 1mV | ||
60.00V | 10mV | ||
60.00V | 100mV | ||
800V | 1V | ||
AC Voltage | 60.00mV | ±1%±3 digit | 10uV |
600.00mV | 100uV | ||
6.00V | 1mV | ||
60.00V | 10mV | ||
600.0V | 100mV | ||
DC Current | 60.00mA | ±1.5%±1 digit | 10uA |
600.00mA | ±1%±1 digit | 100uA | |
6.000A | ±1.5%±3 digit | 1mA | |
10.00A | 10mA | ||
AC Current | 60.00mA | ±1.5%±1 digit | 10uA |
600.00mA | ±1%±1 digit | 100uA | |
6.000A | ±1.5%±3 digit | 1mA | |
10.00A | 10mA | ||
Resistance | 600 | ±1%±3 digit | 0.1Ω |
6.000 K | ±1%±1 digit | 1Ω | |
60.00 K | 10Ω | ||
600.0 K | 100Ω | ||
6.000 M | 1KΩ | ||
60.00 M | ±1.5%±3 digit | 10KΩ | |
Capacitance | 40.00nF | ±1%±1 digit | 10pF |
400.00nF | 100pF | ||
4.000uF | 1nF | ||
40.00uF | 10pF | ||
400.0uF | 100pF | ||
Attention: The smallest capacitance value that can be measured in 5nF | |||
Diode |
0V~2.0V |
|
|
|
|
