Features

Excellent industrial design-the same anodised aluminium casing as iPad, which is not only beautiful and tasteful but also greatly enhanced the hardness of aluminum alloy surface, and has good heat resistance and strong wearability.
Standard USBXI^TM interface, easily inserts into USBXI^TM housing to make up a combination instrument.
USB2.0 interface, no external power source required, easy to use.
Be suitable for notebook computer, product line maintenance, be used easily on business.
Dimensions (mm):205(L) x120(W) x35(H), be carried easily.
High performance, 48MS/s real-time sampling, 20MHz bandwidth.
16Channels Logic Analyzer, 10MHz Bandwidth;
Operating System: Windows 7, Windows 8, Windows 10.
20 measurement functions.
intensity, invert, addition, subtraction, multiplication, division, X-Y plot.
Save waveform in the following: text file, jpg/bmp graphic file, MS excel/word file.
FFT
One computer can connect many DSO, extend channel easily.
Labview\VB\VC Second Design instance.

Function Picture:

Model	Hantek6022BL
Oscilloscope Features
Bandwidth	20MHz
Channel	2(Digital)+16(Logic)
Sample Rate	48MSa/s
Memory Depth	1M
Rise Time	17.5ns
Time Base Precision	±50ppm
Time Base Range	1ns/div-5000s/div (Step by1-2-5)
Input Impendence	1MΩ 25pF
Input Sensitivity	20mV/div～5V/div
Vertical Resolution	8Bit
Vertical Position Range	20mV ~ 5V/div @ x1 probe; 200mV ~ 50V/div @ x10 probe; 2V ~ 500V/div @ x100 probe; 20V ~ 5KV/div @ x1000 probe
DC Accuracy	±3%
Trigger Type	Edge
Trigger Source	CH1, CH2
Math	+,-,x,÷,FFT, Invert
Cursor Measurement	Cross, Horizontal, Vertical
Auto Measurement	Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Mean, Vrms, Vcrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, +Duty Cycle,-Duty Cycle
Logic Analyzer Features
Channel	16
Max. Impendance	1MΩ(C=7.5pF)
Max. Voltage	0V~5.5V
Max. Sample	48M
Bandwidth	10MHz
Compatible Input	TTL, LVTTL, CMOS
Memory Depth	1M/CH
General Features
Power	USB Port
Demensions	200mm x100mm x 35mm
Weight	0.3KG
Standard Probe	2 x PP80B
